Example¶

Here is a pipeline “demo” consisting of three nodes that depend on each other: the task ping_localhost, the pipeline sub_pipeline and the task sleep:

from mara_pipelines.commands.bash import RunBash
from mara_pipelines.pipelines import Pipeline, Task
from mara_pipelines.ui.cli import run_pipeline, run_interactively

pipeline = Pipeline(
    id='demo',
    description='A small pipeline that demonstrates the interplay between pipelines, tasks and commands')

pipeline.add(Task(id='ping_localhost', description='Pings localhost',
                  commands=[RunBash('ping -c 3 localhost')]))

sub_pipeline = Pipeline(id='sub_pipeline', description='Pings a number of hosts')

for host in ['google', 'amazon', 'facebook']:
    sub_pipeline.add(Task(id=f'ping_{host}', description=f'Pings {host}',
                          commands=[RunBash(f'ping -c 3 {host}.com')]))

sub_pipeline.add_dependency('ping_amazon', 'ping_facebook')
sub_pipeline.add(Task(id='ping_foo', description='Pings foo',
                      commands=[RunBash('ping foo')]), ['ping_amazon'])

pipeline.add(sub_pipeline, ['ping_localhost'])

pipeline.add(Task(id='sleep', description='Sleeps for 2 seconds',
                  commands=[RunBash('sleep 2')]), ['sub_pipeline'])

Tasks contain lists of commands, which do the actual work (in this case running bash commands that ping various hosts).

In order to run the pipeline, a PostgreSQL database needs to be configured for storing run-time information, run output and status of incremental processing:

import mara_db.auto_migration
import mara_db.config
import mara_db.dbs

mara_db.config.databases \
    = lambda: {'mara': mara_db.dbs.PostgreSQLDB(host='localhost', user='root', database='example_etl_mara')}

mara_db.auto_migration.auto_discover_models_and_migrate()

Given that PostgresSQL is running and the credentials work, the output looks like this (a database with a number of tables is created):

Created database "postgresql+psycopg2://root@localhost/example_etl_mara"

CREATE TABLE data_integration_file_dependency (
    node_path TEXT[] NOT NULL,
    dependency_type VARCHAR NOT NULL,
    hash VARCHAR,
    timestamp TIMESTAMP WITHOUT TIME ZONE,
    PRIMARY KEY (node_path, dependency_type)
);

.. more tables

CLI UI¶

This runs a pipeline with output to stdout:

from mara_pipelines.ui.cli import run_pipeline

run_pipeline(pipeline)

Example run cli 1

And this runs a single node of pipeline sub_pipeline together with all the nodes that it depends on:

run_pipeline(sub_pipeline, nodes=[sub_pipeline.nodes['ping_amazon']], with_upstreams=True)

Example run cli 2

And finally, there is some sort of menu based on pythondialog that allows to navigate and run pipelines like this:

from mara_pipelines.ui.cli import run_interactively

run_interactively()

Example run cli 3

Web UI¶

More importantly, this package provides an extensive web interface. It can be easily integrated into any Flask based app and the mara example project demonstrates how to do this using mara-app.

For each pipeline, there is a page that shows

a graph of all child nodes and the dependencies between them
a chart of the overal run time of the pipeline and it’s most expensive nodes over the last 30 days (configurable)
a table of all the pipeline’s nodes with their average run times and the resulting queuing priority
output and timeline for the last runs of the pipeline

Mara pipelines web ui 1
